ISSUED: 10-01-10 SHEET #: 056-9034-4 07-29-11
Visit the Peerless Web Site at www.peerlessmounts.com
7 of 10
For customer care call 1-800-865-2112
Threadtwo1/4-20hexthinnylon-insertlocknuts(notincluded)ontwo1/4-20threadedrods(notincluded)tothe
desiredheightofprojectormountassembly.Attachprojectormountassembly(A)tothetwo1/4-20threadedrods
usingtwo1/4-20hexthinnylon-insertlocknutsasshowningure 4.1orgure 4.2.
Installation to Threaded Rod
(Not evaluated by UL - Professional installation only)
4
1/4-20THREADEDROD
(NOTINCLUDED)
A
1/4-20THREADEDROD
(NOTINCLUDED)
A
1/4-20HEXTHIN
NYLON-INSERT
LOCKNUT
(NOTINCLUDED)
1/4-20HEXTHIN
NYLON-INSERT
LOCKNUT
(NOTINCLUDED)
1/4-20HEXTHIN
NYLON-INSERT
LOCKNUT
(NOTINCLUDED)
1/4-20HEXTHIN
NYLON-INSERT
LOCKNUT
(NOTINCLUDED)
ARROW
INDICATES
FRONTOF
MOUNT
ARROW
INDICATES
FRONTOF
MOUNT
g. 4.1
g. 4.2
