26
9. NETWORK SETTINGS
Advanced Settings (Profile 1 / Profile 2)
Item Description Remarks
Site survey
• Run the site survey and display the detected access
points.
• Amaximumof64accesspointscanbedisplayed.
• Only1accesspointwiththesamenameasSSIDisdis-
played.
• The applicable access points are the security-disabled
WPA-PSK, WPA2- PSK, WPA-EAP and WPA2-EAP.
• A“Key”markisattachedwhenthesecuritysettingofthe
access point has been enabled.
Selection is not possible if this
device is not connected to a
wireless LAN unit.
NOTE: If anyaccesspoint is not
searched, select the site survey
againafterselecting[RECONNECT]
onthewirelessLANscreen.
Security setting Select the type of security.
• Disable:Disablethesecuritysetting.
• WPA2-PSK:Inputcolumnofthekeyisdisplayed.
• WPA/WPA2-PSK:Inputcolumnofthekeyisdisplayed.
• WPA2-EAP:Authenticationsettingsaredisplayed.
• WPA/WPA2-EAP: Authentication settings items are dis-
played
• The default factory setting
when shipped is “Disable”.
SSID Set the SSID. This consists of 1 - 32 half-byte
alphanumeric characters.
The default factory setting when
shippedis“NECPJ”.
[AUTHENTICATION]
Setting is required for using WPA2-EAP or WPA/WPA2-EAP.
Preparation before setting
SelectawirelessLANcompliantWPA-EAPorWPA2-EAPauthenticationandinstalladigitalcerticateontheprojec-
tor.
1. Set [DATE AND TIME] and [TIME ZONE] on the projector. (→ page 39)
2. Use a computer to save digital certificates (files) for WPA2-EAP setting to your USB memory device.
After completing saving the file, remove the USB memory device from the computer.
Important:
• Thesupportedleextensionsforclientcerticateare".pfx"and".p12",forrootcerticateare".cer"and".der".
• TheleformatsofdigitalcerticatethataresupportedbytheprojectorareDERandPKCS#12only.
• Theprojectorcannothandleanydigitalcerticatewhoselesizeexceeds8KB.
3. Plug the USB memory device into the USB port of the projector.
Setting Procedures
1. Select either [WPA2-EAP] or [WPA/WPA2-EAP] for the [SECURITY TYPE] on the [SECURITY] page
The pull-down list will be displayed.
2. Focus on the [AUTHENTICATION].
Select either [EAP-TLS] or [PEAP-MSCHAPV2] for [EAP TYPE]. The setting items vary depending on the EAP
type.
