2. Installation and Connections
33
Connecting an External Monitor
Connect an external monitor to the projector through RGB out connections as shown be-
low (see item 4, Terminal Panel Features on page 10).
Note:
• Daisy chain connection is not possible.
• The MONITOR OUT connector will output no video signal (Digital signal) from
the COMPUTER 3 IN connector.
• When audio equipment is connected, the projector speaker is disabled.
