2. Installation and Connections
35
Connecting Your VCR
To connect you VCR, refer to the following diagram.
Note:
Refer to your VCR owner’s manual for more information about your device’s re-
quirements.
Images may not be displayed correctly when using an S-Video or Video connec-
tion to fast-forward or fast-rewind scanning.
The AUDIO IN RCA jack is shared between VIDEO IN and S-VIDEO IN.
