3. Projecting an Image (Basic Operation)
43
Lens Shift Adjustable Range
The adjustable range for lens shift is tabulated below and subject to the conditions listed.
Note:
The drawings below are applied to the lenses for NP07ZL, NP08ZL, NP09ZL, and
NP10ZL. The lens for NP06FL does not have a lens shift feature.
From the Remote Control Unit
1.
Press the Lens Shift but-
ton to bring up the Lens
Shift window.
To Next Page
