NEC PA600X User Manual

8
1. Introduction
 Part Names of the Remote Control
1. Infrared Transmitter
(→page9)
2. POWER ON Button
(→page14)
3. POWEROFFButton
(→page25)
4,5,6.COMPUTER1/2/3Button
(→page16)
7. AUTO ADJ. Button
(→page24)
8. VIDEOButton
(→page16)
9. S-VIDEOButton
(→page16)
10.HDMIButton(→page16)
11. DisplayPort Button (→page16)
12.VIEWERButton(→page16, 60)
13.NETWORKButton(→page16)
14.SOURCEButton(→page16)
15.PIPButton(→page16, 35)
16.IDSETButton(→page107)
17.NumericKeypadButton/CLEARButton
(→page107)
18. MENU Button (→page82)
19. EXIT Button (→page82)
20. Button (→
page82)
21. ENTER Button (→page82)
22.L-CLICKButton*(→page31)
23.R-CLICKButton*(→page31)
24.VOLUME(+)(−)Button(→page24)
25.D-ZOOM(+)(−)Button(→page27)
26.PAGE/Button*(→page31)
27. PICTURE Button (→page91, 93)
28. ECO Button (→page28)
29. ASPECT Button (→page96)
30.AV-MUTEButton(→page27)
31.3DREFORMButton(→page32)
32.FREEZEButton(→page27)
33.SHUTTERButton
 (notavailableonthisseriesofprojectors)
34.LENSSHIFTButton
 (notavailableonthisseriesofprojectors)
35.FOCUS/ZOOMButton
 (notavailableonthisseriesofprojectors)
36.HELPButton(→page112)
* ThePAGE/, ,L-CLICKandR-CLICKbuttonsworkonlywhenaUSBcableisconnectedwithyourcom-
puter..
1
3
5
4
8
9
12
13
2
6
7
11
10
15
14
17
16
18
22
24
25
27
28
21
19
20
23
26
29
30
33
34
32
31
36
35
