NEC PA600X - Zoom; Adjusting the Tilt Feet

21
2. Projecting an Image (Basic Operation)
Adjusting the Tilt Feet
1. Turntheleftandrighttiltfeettoadjust.
 Thetiltfeetlengthenandshortenwhenturned.
 Theheightoftheprojectedimageisadjustedbyturningtheleft
and right tilt feet.
If the projected image is tilted, turn one of the tilt feet to adjust
the image so that it is level.
- If the projected image is distorted, see “2-6 Correcting Keystone
Distortion” (→ page 22).
- The tilt feet can be lengthened by a maximum of 20 mm.
- The tilt feet can be used to tilt the projector by a maximum of 4º.
NOTE:
• Donotlengthenthetiltfeetanymorethan20mm/0.8".Doingsowillmakethe
tiltfeet’smountsectionunstableandcouldcausethetiltfeettocomeoffthe
projector.
• Donotuse thetiltfeet foranypurpose otherthanadjusting theprojector’s
projectionangle.
 Handlingthetiltfeetimproperly,suchascarryingtheprojectorbygraspingthetilt
feetorhookingitontoawallusingthetiltfeet,coulddamagetheprojector.
Zoom
Turnthezoomleverorzoomringclockwiseandcounterclockwise.
- TheseparatelysoldNP11FLlensdoesnothaveazoomring.
Zoom ring
Up
Tilt foot
Down
