1. Introduction

 Introduction to the Projector

Thissectionintroducesyoutoyournewprojectoranddescribesthefeaturesandcontrols.

Congratulations on Your Purchase of the Projector

Thisprojectorisoneoftheverybestprojectorsavailabletoday.Theprojectorenablesyoutoprojectpreciseimages

upto500inchesacross(measureddiagonally)fromyourPCorMacintoshcomputer(desktopornotebook),VCR,

DVDplayer,ordocumentcamera.

Youcanusetheprojectoronatabletoporcart,youcanusetheprojectortoprojectimagesfrombehindthescreen,

andtheprojectorcanbepermanentlymountedonaceiling*

.Theremotecontrolcanbeusedwirelessly.

 Donotattempttomounttheprojectoronaceilingyourself.

 Theprojectormustbeinstalledbyqualiedtechniciansinordertoensureproperoperationandreducetherisk

ofbodilyinjury.

 Inaddition,theceilingmustbestrongenoughtosupporttheprojectorandtheinstallationmustbeinaccordance

withanylocalbuildingcodes.Pleaseconsultyourdealerformoreinformation.

Features you’ll enjoy:

• Liquidcrystaltypehighbrightness/highresolutionprojector

Model LCDpanel Resolution AspectRatio

PA600X 0.79"(withMLA) 1024×768dots 4:3

PA500X

0.79"(withMLA) 1024×768dots 4:3

PA550W

0.75"(withMLA) 1280×800dots 16:10

PA500U

0.76"(withMLA) 1920×1200dots 16:10

 ThePA600X/PA500X/PA550WprojectorscoverinputsignalsuptoWUXGA(1920×1200dots)thankstothe

AdvancedAccuBlendfunction.

• Widerangeofoptionallensesselectableaccordingtotheplaceofinstallation

 Thisprojectorsupports5typesofoptionallenses,providingaselectionoflensesadaptedtoavarietyofplaces

ofinstallationandprojectionmethods.

 Inaddition,thelensescanbemountedandremovedinonetouch.

 Notethatnolensismounteduponshipmentfromthefactory.Pleasepurchaseoptionallensesseparately.

• Lensshiftfunctionforeasilyadjustingthepositionoftheprojectedimage

 Thepositionoftheprojectedimageismovedbyturningthetwodialsontheprojector’sfront,oneforthevertical

direction,oneforthehorizontaldirection.

• 360°installationangle(tilt-free)

 Theprojectorcanbeinstalledatanyangle(360°).

 Note,however,thatthe“fanmode”settingmustbechangedaccordingtotheangleofinstallation.

 Also,theprojectorcannotbeinstalledtiltedtotheleftorright.

• Widerangeofinput/outputconnectors(HDMI,DisplayPort,BNC,etc.)andbuilt-inmonauralspeaker

 Theprojector isequippedwith a varietyof input/outputconnectors:computer (analog), 5-coreBNC,HDMI,

DisplayPort,Video,S-Video,etc.(Thecomputer(analog)andBNCconnectorsalsosupportcomponentinputs.)

 Theprojector’sHDMIandDisplayPortinputconnectorssupportHDCP.

 Theprojectorisalsoequippedwithabuilt-in10Wmonauralspeaker.

• Highpicturequalityprocessingcircuit

 IDTHQVprocessingtechnologyisusedtoprojecthighqualityimages.

• Energy-savingdesignwithastandbypowerconsumptionof0.2watts

 Whentheon-screenmenu’sstandbymodeissetto“PowerSaving”,thepowerconsumptioninthestandbymode

is0.2watts.

Downloaded From projector-manual.com NEC Manuals

Other manuals for NEC PA600X

Quick Setup Guide6 pages

Questions and Answers:

Need help?

Do you have a question about the NEC PA600X and is the answer not in the manual?

NEC PA600X Specifications

General

Matrix size	0.8 \
Projection distance	0.74 - 20.9 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	15 - 108 kHz
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	25 - 500 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	30 °
Keystone correction, horizontal	40 °
Audio input	1
Aspect ratio	-
Dimensions (WxDxH)	499 x 366 x 164 mm
Maximum analog resolution	1920 x 1200 pixels
Focus	Manual
Focal length range	24.4 - 32.5 mm
Lamp power	330 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Ethernet LAN	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power	10 W
Product type	Large venue projector
Product color	White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	16 W
Power consumption (typical)	464 W
Power consumption (PowerSave)	372 W
Noise level	38 dB
Certification	UL, C-UL, NOM
Noise level (economic mode)	31 dB
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	VGA
