NEC PA600X User Manual

vii
Table of Contents
ChangingEcoMode/CheckingEnergy-SavingEffectUsingEcoMode[ECO
MODE] ................................................................................................................... 28
CheckingEnergy-SavingEffect[CARBONMETER] ............................................. 29
 UsingtheOptionalRemoteMouseReceiver(NP01MR) ............................................ 30
 CorrectingHorizontalandVerticalKeystoneDistortion[CORNERSTONE] ................ 32
Cornerstone ........................................................................................................... 32
 DisplayingTwoPicturesattheSameTime .................................................................. 35
SelectingthePIPorPICTUREBYPICTUREMode[MODE] ................................ 35
[POSITION] ............................................................................................................ 36
 PreventingtheUnauthorizedUseoftheProjector[SECURITY] ...................................... 37
ControllingtheProjectorbyUsinganHTTPBrowser ................................................. 40
ProjectingYourComputer’sScreenImagefromtheProjectorviaaNetwork
[NETWORKPROJECTOR] .................................................................................... 47
UsingtheProjectortoOperateYourComputerviaaNetwork[REMOTE
DESKTOP] ............................................................................................................. 51
4. Using the Viewer ............................................................................................. 56
❶WhatyoucandowiththeViewer ................................................................................. 56
❷Preparingpresentationmaterials ................................................................................ 59
❸ProjectingimagesstoredinaUSBmemorydevice .................................................... 60
StartingtheViewer ................................................................................................. 60
ExitingtheViewer .................................................................................................. 63
NamesandfunctionsofViewerscreen .................................................................. 64
Vieweroptionsettings ............................................................................................ 69
❹Projectingdatafromsharedfolder .............................................................................. 72
Connectingtheprojectortothesharedfolder ....................................................... 72
Disconnectingthesharedfolderfromtheprojector ............................................... 75
❺Projectingdatafrommediaserver............................................................................... 76
Settingup“MediaSharing”inWindowsMediaPlayer 11 ...................................... 76
Settingup“MediaSharing”inWindowsMediaPlayer12 ...................................... 78
Connectingtheprojectortothemediaserver ........................................................ 79
Disconnectingtheprojectorfromthemediaserver ............................................... 80
❻Restrictionsondisplayingles .................................................................................... 81
SomerestrictionsonPowerPointles .................................................................... 81
SomerestrictionsonPDFles .............................................................................. 81
5. Using On-Screen Menu ................................................................................ 82
1UsingtheMenus .......................................................................................................... 82
MenuElements ............................................................................................................ 83
ListofMenuItems ....................................................................................................... 84
MenuDescriptions&Functions[SOURCE] ................................................................ 87
COMPUTER1, 2, and 3 ........................................................................................ 87
HDMI ...................................................................................................................... 87
DisplayPort ............................................................................................................. 87
VIDEO .................................................................................................................... 87
S-VIDEO ................................................................................................................ 87
VIEWER ................................................................................................................. 87
NETWORK ............................................................................................................. 87
Downloaded From projector-manual.com NEC Manuals

NEC PA600X Specifications

General

Matrix size	0.8 \
Projection distance	0.74 - 20.9 m
Vertical scan range	48 - 120 Hz
Horizontal scan range	15 - 108 kHz
Projection technology	LCD
Contrast ratio (typical)	2000:1
Screen size compatibility	25 - 500 \
Projector native resolution	XGA (1024x768)
Keystone correction, vertical	30 °
Keystone correction, horizontal	40 °
Audio input	1
Aspect ratio	-
Dimensions (WxDxH)	499 x 366 x 164 mm
Maximum analog resolution	1920 x 1200 pixels
Focus	Manual
Focal length range	24.4 - 32.5 mm
Lamp power	330 W
Light source type	Lamp
Service life of light source	3000 h
Service life of light source (economic mode)	4000 h
DVI port	No
Serial interface type	RS-232
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
VGA (D-Sub) ports quantity	3
Ethernet LAN	Yes
Supported video modes	1080i, 1080p, 480i, 480p, 576i, 576p, 720p
Analog signal format system	NTSC, NTSC 4.43, PAL, PAL M, PAL N, SECAM
Supported graphics resolutions	1024 x 768 (XGA), 1280 x 1024 (SXGA), 1400 x 1050 (SXGA+), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA)
RMS rated power	10 W
Product type	Large venue projector
Product color	White
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (standby)	16 W
Power consumption (typical)	464 W
Power consumption (PowerSave)	372 W
Noise level	38 dB
Certification	UL, C-UL, NOM
Noise level (economic mode)	31 dB
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	5 - 40 °C
Operating relative humidity (H-H)	20 - 80 %
Cables included	VGA

Weight and Dimensions

Weight	7700 g
