NEC PlasmaSync 42MP2 User Manual

42
20. VIDEO ADJ Request
Function
The display returns the video adjustments information by the external control
equipment’s request.
Transmission Data
1FH 80H 60H 45H 00H CKS
ACK
7FH 60H 80H 45H 0CH DATA00 to DATA0B CKS
DATA00: RED Gain(Bias) D8H: -40
FFH: -1
00H: 0
28H: +40
DATA01: GREEN Gain(Bias) D8H: -40
FFH: -1
00H: 0
28H: +40
DATA02: BLUE Gain(Bias) D8H: -40
FFH: -1
00H: 0
28H: +40
DATA03: COLOR Gain EAH: -22
FFH: -01
00H: 0
01H: +01
16H: +22
DATA04: TINT Gain EAH: -22
FFH: -01
00H: 0
01H: +01
16H: +22
DATA05: SHARPNESS Gain F0H: -16
FFH: -01
00H: 0
01H: +01
10H: +16
DATA06: CONTRAST Gain 00H: 0
34H: +52
DATA07: BRIGHT Gain E0H: -32
FFH: -01
00H: 0
01H: +01
20H: +32
DATA08: RED Gain(Drive) D8H: -40
FFH: -1
00H: 0
28H: +40
DATA09: GREEN Gain(Drive) D8H: -40
FFH: -1
00H: 0
28H: +40
DATA0A: BLUE Gain(Drive) D8H: -40
FFH: -1
00H: 0
28H: +40
DATA0B: COLOR TEMP 00H: 1
01H: 2
02H: 3
03H: PRO
