NEC PlasmaSync 42XR4 User Manual

En-23
SET UP Settings Menu
Setting the language for the menus
The menu display can be set to one of eight languages.
Example: Setting the menu display to “DEUTSCH”
On “LANGUAGE” of “SET UP” menu, select “DEUTSCH”.
SEL. ADJ. RETURN
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
: DEUTSCH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF
EXIT
Information
䡵 Language settings
ENGLISH ........English
DEUTSCH.......German
FRANÇAIS ...... French
ESPAÑOL .......Spanish
ITALIANO .......Italian
SVENSKA ......Swedish
У .......... Russian
PORTUGUÊS ..... Portuguese
Checking the signal being transmitted to PC/
RGB terminal
Set “ADVANCED OSM” to “ON” in the FUNCTION menu.
Use this to confirm the signal being transmitted to the PC/
RGB terminal.
It is set to RGB and can not be adjusted.
CAN NOT ADJUST
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF
Setting high definition images to the suitable
screen size
Use this procedure to set whether the number of vertical
lines of the input high definition image is 1080I or 1035I
or 540P.
Example: Setting the “HD SELECT” mode to “1035I”
Set “ADVANCED OSM” to “ON” in the FUNCTION menu.
On “HD SELECT” of “SET UP” menu, select “1035I”.
SEL. ADJ. RETURN
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
: ENGLISH
: COMPONENT
: RGB
: 1035I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF
EXIT
Information
䡵 HD SELECT modes
These 3 modes are not displayed in correct image
automatically.
1080I: Standard digital broadcasts
1035I: Japanese “High Vision” signal format
540P: Special Digital broadcasts (for example :
DTC100)
Setting a computer image to the correct RGB
select screen
With the computer image, select the RGB Select mode
for a moving image such as (video) mode, wide mode or
digital broadcast.
Example: Setting the “RGB SELECT” mode to
“852⳯480 ”
Set “ADVANCED OSM” to “ON” in the FUNCTION menu.
On “RGB SELECT” of “SET UP” menu, select “852⳯480”.
SEL. ADJ. RETURN
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
: ENGLISH
: COMPONENT
: RGB
: 1080I
: 852⳯480
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF
EXIT
Checking the signal being transmitted to
DVD/HD1 terminal
Set “ADVANCED OSM” to “ON” in the FUNCTION menu.
Use this to confirm the signal being transmitted to DVD/
HD1 terminal.
It is set to COMPONENT and can not be adjusted.
SET UP
LANGUAGE
DVD/HD1 INPUT
D-SUB INPUT
HD SELECT
RGB SELECT
HDMI SET UP
COLOR SYSTEM
BACK GROUND
GRAY LEVEL
S1/S2
DISPLAY OSM
OSM ADJ.
REMOTE ID
ALL RESET
: ENGLISH
: COMPONENT
: RGB
: 1080I
: AUTO
: HIGH
: AUTO
: GRAY
: 3
: OFF
: ON
: TOP LEFT
: ALL
: OFF
CAN NOT ADJUST
