Installation Guide

QX-S5500G Series Ethernet Switches

1. Product overview

1-1

1. Product overview

1.1 QX-S5524GT-4X2Q panel views

Figure 1-1 QX-S5524GT-4X2Q front panel

(1) 10/100/1000 BASE-T autosensing Ethernet port

(2) 10/100/1000 BASE-T autosensing Ethernet port LED

(3) SFP+ port

(4) Console port

(5) USB mini Console port

(6) Port LED mode switching button

(7) Port mode LED

(8) USB port

(9) System status LED (SYS)

(10) RPS status LED (RPS)

(11) SFP+ port LED

Figure 1-2 QX-S5524GT-4X2Q rear panel

(1) QSFP+ port LED

(2) QSFP+ port

(3) AC-input power receptacle

(4) RPS receptacle

(5) Grounding screw
