Necchi NL11C - Changing the Needles

6
Changing the needles
n
Attention
Turno󰀨themainpowerswitchandunplug
the machine.
1. Turn the hand wheel toward you until the
needles are at the highest position.
2. Loosen, but do not remove the left or right
needle clamp screw with the allen key
while you are holding the needles.
3. Remove the left or right needle,
depending on the stitch type you want to
sew.
4. Holdthenewneedle(s)withtheat
surface to the back.
5. Inserttheneedle(s)intotheleftand/or
right needle clamp as far as it/they will go.
6. Securely tighten the left or right needle
clamp screw.
1
Right needle clamp screw
2
Left needle clamp screw
Note
When using both needles, the left needle
is positioned a little higher up than the right
needle(theyarenotsupposedtobe‘level’,
like a twin needle).
1
2
