Necchi NL11C - Attach the 2-Thread Overlock Converter; Remove the 2-Thread Overlock Converter

8
Attach the 2–thread overlock converter
Note
2-thread overlock stitches are sewn using
one needle thread and the lower looper
thread. Before sewing, the two-thread
converter must be attached to the upper
looper, so the machine will sew with only
two threads.
Open the front cover.
Bring the upper looper to its higher position
by turning the hand wheel toward you.
1
2-thread overlock converter
2
Upper looper
Insertthetipoftheconverter(A)intothehole
oftheupperlooper(B).
Push the converter down into the slot of the
upper looper.
v
Remove the 2-thread overlock
converter
Remove the converter by tilting it toward you.
1
A
B
2
