INITIALS DESCRIPTION
WIRING DIAGRAM LEGEND
INITIALS DESCRIPTION
38
CM1-2 COFFEE UNIT MOTOR CAM
CV VOLUMETRIC COUNTER
E1-... INSTANT SOLENOID VALVE
EEA WATER INLET SOLENOID VALVE
ER COFFEE DISPENSER SOLENOID VALV
ESC COFFEE RELEASE MAGNET
EX EXECUTIVE COIN MECH CONNECTOR
FA RADIO INTERFERENCE SUPPRESS
ID COFFEE DOSE SWITCH
IP DOOR SWITCH
IPF WASTE CONTAINER OVERFLOW SWITCH
IVA EMPTY BOILER MICRO-SWITCH
KC1-.. COFFEE BOILER CUTOUT
KS1-.. SAFETY CUTOUT
LCD LIQUID CRYSTAL DISPLAY
M COFFEE UNIT MOTOR
MAC GRINDER
MD1-.. INGREDIENT MOTOR - INSTANT
MDB CONNECTOR FOR MDB COIN MECHANISM
MF1-.. WHIPPER MOTORS
NTC TEMPERATURE PROBE
PM PUMP
RCC COFFEE BOILER HEATING ELEMENT
RIS COFFEE UNIT HEATER
RS232 SERIAL PORT
SM CONTROL BOARD
SP PUSH-BUTTON BOARD
TR TRANSFORMER
TR1 230 V-24 V TRANSFORMER
TX.... DELAYED FUSE (X=CURRENT)
VAR VARISTOR
VENT FAN
