Nederman FlexPAK 1000 User Manual

FlexPAK 800/1000
EN
18
FlexPAK 1000
Weight 439 kg (968 lb) 439 kg (968 lb) 439 kg (968 lb)
Inlet/outlet diameter 150/160 mm (7.87/6.29") 150/160 mm (7.87/6.29") 150/160 mm (7.87/6.29")
Sound level 70 dB(A) 70 dB(A) 70 dB(A)
Filtraon eciency* Dust class L Dust class L Dust class L
Maximum ambient
temperature
-10 – +40 °C (14–104 °F) -10 – +40 °C (14–104 °F) -10 – +40 °C (14–104 °F)
Relave humidity Max. 85% Max. 85% Max. 85%
Compressed air 6–7 bar (87–102 PSI) 6–7 bar (87–102 PSI) 6–7 bar (87–102 PSI)
Material recycling 93.6% per weight 93.6% per weight 93.6% per weight
Control Filter area 1x12 m² (1x129 sq) 1x12 m² (1x129 sq) 1x12 m² (1x129 sq)
Control Filter material Polyester Polyester Polyester
* According to DIN EN/IEC 60335-2-69.
3.4 Fuses
Table 3-3: Fuses
Fuse Size Type
Main fuse F1, 230 V 65 A Slow mains fuses
Main fuse F1, 400 V 35 A Slow mains fuses
Main fuse F1, 460 V 40 A Slow mains fuses
Transformer, primary fuse F2 and F3 0,8 A* Slow fuses, 10.3×38
Transformer, secondary protecon PTC resistor
F4 50 mA* Fast, 5×20
F5 1 A* Slow, 5×20
* General size, see also the included electrical diagrams.
3.5 Main components
WARNING! Explosion risk.
Never use the unit without a plasc bag.
CAUTION! Risk of equipment damage.
Use Nederman original bags only.
Figure 3, 4 and 5 show the main components of the unit:
1. Collector bin, see gure 3.
2. Dust extractor, see gure 3.
3. Texle lter bags, see gure 3.
4. Filter holder, see gure 3.
5. Filter Cleaning Valve (FCV), see gure 3.
6. Connecon duct from the dust extractor to the inlet silencer, see gure 3.
7. Start and control unit, see gure 3 and 4.
8. Control panel, see gure 3 and 4.
