FlexPAK 800/1000
13
EN
Automac lter cleaning
FlexPAK 800/1000 uses lter cleaning by a short blast of reversed air ow with atmospheric
pressure. By the rapid opening of the Filter Cleaning Valve (FCV) located on top of the lter,
a powerful blast of reversed air ow is created, eciently dislodging dust from the lter
bags, see gure 8.
3.2 Dimensions
For the dimensions of FlexPAK 800/1000, see gure 2.
3.3 Technical data
Table 3-1: Technical data FlexPAK 800
FlexPAK 800
Eect
18.5 kW (25 hp) 18.5 kW (25 hp) 21.5 kW (29 hp)
Mains voltage/frequency 230 V±10%/50–60 Hz 400 V±10%/50–60 Hz 460 V±10%/50–60 Hz
Maximum ow 1,300 m
3
/h (765 cfm) 1,300 m
3
/h (765 cfm) 1,300 m
3
/h (765 cfm)
Flow at -20 kPa 800 m
3
/h (470 cfm) 800 m
3
/h (470 cfm) 800 m
3
/h (470 cfm)
Maximum vacuum -35 kPa (-5.1 PSI) -35 kPa (-5.1 PSI) -35 kPa (-5.1 PSI)
Filter area 6 m
2
(64.5 sq) 6 m
2
(64.5 sq) 6 m
2
(64.5 sq)
Weight 439 kg (968 lb) 439 kg (968 lb) 439 kg (968 lb)
Inlet/outlet diameter
(anged)
150/160 mm (7.87/6.29") 150/160 mm (7.87/6.29") 150/160 mm (7.87/6.29")
Sound level 70 dB(A) 70 dB(A) 70 dB(A)
Filtraon eciency* Dust class L Dust class L Dust class L
Maximum ambient
temperature
-10 – +40 °C (14–104 °F) -10 – +40 °C (14–104 °F) -10 – +40 °C (14–104 °F)
Relave humidity Max. 85% Max. 85% Max. 85%
Compressed air
6–10 bar (87–102 PSI) 6–10 bar (87–102 PSI) 6–10 bar (87–102 PSI)
Material recycling 93.6% per weight 93.6% per weight 93.6% per weight
* According to DIN EN/IEC 60335-2-69.
Table 3-2: Technical data FlexPAK 1000
FlexPAK 1000
Eect
18.5 kW (25 hp) 18.5 kW (25 hp) 21.5 kW (29 hp)
Mains voltage/frequency 230 V±10%/50–60 Hz 400 V±10%/50–60 Hz 460 V±10%/50–60 Hz
Maximum ow 1,300 m
3
/h (765 cfm) 1,300 m
3
/h (765 cfm) 1,300 m
3
/h (765 cfm)
Flow at -15 kPa 1000 m
3
/h (588 cfm) 1000 m
3
/h (588 cfm) 1000 m
3
/h (588 cfm)
Maximum vacuum -20 kPa (-2.9 PSI) -20 kPa (-2.9 PSI) -20 kPa (-2.9 PSI)
Filter area 6 m
2
(64.5 sq) 6 m
2
(64.5 sq) 6 m
2
(64.5 sq)
Weight 439 kg (968 lb) 439 kg (968 lb) 439 kg (968 lb)
Inlet/outlet diameter 150/160 mm (7.87/6.29") 150/160 mm (7.87/6.29") 150/160 mm (7.87/6.29")
Sound level 70 dB(A) 70 dB(A) 70 dB(A)
Filtraon eciency* Dust class L Dust class L Dust class L
Maximum ambient
temperature
-10 – +40 °C (14–104 °F) -10 – +40 °C (14–104 °F) -10 – +40 °C (14–104 °F)
