18
@ @ 1
4.1 ATEX designation
Pos: 9.12 /Betriebsanleitung/Leerzeile Halb @ 10\mod _1478598405587_0.docx @ 209639 @ @ 1
Pos: 9.13 .1 /BA Nederman Filtration/Üb erschriften/1.1.1/Filter @ 27 \mod_1511166502528_9879.docx @ 268539 @ @ 1
With regard to the requirements of Directive 2014/34 / EC and ISO EN 80079-36 product is
marked as follows:
Pos: 9.15 .2 /Betriebsanleitung/Leerzeile Halb @ 10\mod_147859840 5587_0.docx @ 209639 @ @ 1
Pos: 9.15 .3 /BA Nederman Filtration/04 Explosion sschutz/Kennzeichnung ATEX/Pro duktkennzeichnung (NEU)/Außenzone: 22 / FM*Z oder M*P oder FlexFilter @ 43\ mod_1572429990018 _0.docx @ 34487 9 @ @ 1
Pos: 9.15 .4 /Betriebsanleitung/Leerzeile Halb @ 10\mod_147859840 5587_0.docx @ 209639 @ @ 1
CE - European mark of conformity (French: Conformité Européenne).
Ex - marking of protective system intended for use in potentially explosive
atmospheres, according to the provisions of Directive 2014/34/UE.
II - equipment group.
1D(3D)/- - marking of the filter protection system intended for use in potentially explosive
atmospheres due to the presence of dust.
Optional filter can be adapted to work with the atmosphere outside, he will have a mark:
1D(3D)/3D
3D/- - designation of the protective system of the fan intended for use in potentially
explosive atmospheres due to dust presence.
Optional fan can be adapted to work with the atmosphere outside, he will have a mark:
3D/3D
c - type of ignition protection.
Ex h - marking of compliance with the level of protection of the equipment.
IIIC - dust group for the filter.
IIIB - dust group for the fan.
°F - maximum surface temperature.
Da(Dc)/- – internal / external protection level of the filter.
optionally, the filter can be adapted to work with the outside atmosphere, it will be
marked:
Da(Dc)/Dc
Dc/- – internal / external protection level of the fan
optionally, the fan can be adapted to work with the atmosphere outside, it will be marked
with:
Da/Dc
