Nedo COMMANDER H2N - Back; Equipment Configuration Commander 2 H2 N;H2 N; Front

39EN Operating instructions 39
1
2
4
5
6
7
1 Battery compartment
2 Fixing clip fixing M6 thread
3 Conical clip guide
4 Sound signal - output
5 LCD display for remote control
6 LCD display for laser receiver
7 LED laser level indicator
1 Keypad
2 LCD display for remote control
3 LCD display for laser receiver
4
Spirit level for aligning for marking
work
5 LED laser level indicator
6
Setpoint level middle marking
(50 mm from top of housing)
7 Laser reception field (70mm)
1
2
3
4
5
7
10 Equipment configuration
COMMANDER 2 H2N/H2N+
10.1 Front
10.2 Back
3
6
