3.8.4. Wiegand output settings
◆ [Ent-] Æ [6] Æ ‘084265’ [Ent] Æ [4] ◆
Wiegand Out:0
0=None 1=26bit
2=34bit
Default setting: ‘0’
When this is set to [1], “Site code + user ID” is sent to the Wiegand port of the
terminal when authentication is done. It can be used only for systems where
there is a lock controller and the controller is operated by a Wiegand input. This
is usually set to [0].
- If it is set to ‘1’, user ID shall be shorter than 4 digits because “Site code [1
byte] + user ID [2 bytes]” is transferred.
- If it is set to ‘2’, user ID shall be shorter than 7 digits because “Site code [1
byte] + user ID [3 bytes]” is transferred.
※ this is not effective when a Wiegand-type card reader is used, and set the
following site code when the setting is higher than ‘1’
<Site code>
(0-255):000
Default setting: ‘0’
This is only available when Wiegand Out is set to ‘1’ or ‘2’. Enter the site code
(0-255) to be sent to the Wiegand port together with the user ID 니다.
Once the setting is complete, press [ENT] to move to the upper menu.
3.8.5. Terminal initialization
In the main menu, press [6] to select “6. Device” and then press [6] to select “6.
Initialize” and the following screen will be appeared:
1. Init Config
2. Delete Log
3. Init Terminal
Press [1] for settings initialization,
press [2] for authentication
record initialization,
press [3] for factory initialization.
To Next Page
