18
-Power LED: The Green LED light indicates that system power on
-Fan and Thermal:
The Green LED light indicates that the system fan and thermal are in normal
status.
The Red LED light indicates that the system fan and thermal are failed,
3. Reset Button of system alarm
Once the system fan is failed and system temperature is over high, the system
buzzer will be alarmed, Press this button to re-set the system alarm
4. HDD LED indicators
Left Green LED indicates HDD Power on
Right LED : The origin LED light indicates the HDD is being access
The red LED light indicates the HDD Fail
5. Power button
Press the button to turn on or off the Digital Video Recorder
6. USB port
This is used to connect USB storage devices for the use of data export
7. Card Reader
To connect the storage devices including Compact Flash, Smart Media, Memory
Stick, Secure Digital, Multi Media, IBM Micro Drive and PCMCIA-ATA card for
back-up purpose
8. CD-RW
For back-up purpose
Rear View
Please refer to Figure 1-3 and the descriptions that follow to identify the
components on the rear side of the Digital Video Recorder.
Note !
When the Red LED is keeping blinking, please call help from
your distributor
