Net.DO Lighting Control Equipment Co.,Ltd http://www.netdo.com.cn
FOX512 Moving Light Controller. PAGE: 28
9.8.4 Connect “Multi-Step Program”
The “Multi-Step Program” control area (as shown on the right)
can control the program (its number will be displayed in LCD
screen) which is connected to the area.
2 ways to connect:
First: Push Playback Fader or press Attribute Key to connect the corresponding program.
(Indicator of corresponding Attribute Key will flash fast)
Second: Press TIME/PB key to enter Playback menu, then press Attribute Key to connect
the corresponding program. This method can avoid to affect the output when connecting.
9.8.5 Control “Multi-Step Program”
GO/STOP: Program can be run and stopped by pressing GO/STOP key after it is connected
to the control area;
STEP ：Running direction of program can be changed by pressing STEP key after
it is connected to the control area; This key can also be used in STOP status to manually run
steps gradually.
9.9 Fader Time of Playback
Every program has its own fader time of playback, users have to know them well to get good grasp
of a show. The fader time of HTP channel and LTP channel is introduced individually as follows:
HTP Time
HTP Time of Fade In: The time needed for HTP channel value to go from 0 to 100% after the
Playback Fader is pushed up.
HTP Time of Fade Out: The time needed for HTP channel value to go from 100% to 0 after the
Playback Fader is pulled down to bottom.
(Diagram of HTP Time)
LTP Time
LTP Time of Fade In: The time needed for LTP channel value to go from original value to next
value after the Playback Fader is pushed up.
(Diagram of LTP Time)
