CORSIGHT PC system adapter cable, DP++ connector
CORSIGHT PC system adapter cable, USB connector
CORSIGHT PC system adapter cable, D-sub 9-pin connectors (RS-232)
PC system connector,
pinout (including pin numbers on the DP++/USB/RS232 adapter cable)
M16
Signal
DP
USB
RS-232
1
ML0+
12
---
---
2
ML3-
1
---
---
3
ML2+
6
---
---
4
ML2-
4
---
---
5
ML3+
3
---
---
6
ML0-
10
---
---
7
ML1+
9
---
---
8
ML1-
7
---
---
9
AUX -
17
---
---
10
GND
2,5,8,11,16
---
---
11
Hot Plug
18
---
---
12
+5V
---
---
---
13
+5V
---
---
---
14
GND
---
4
---
15
GND
---
---
---
16
AUX +
15
---
---
17
USB-
---
2
---
18
+5V USB
---
1
---
19
GND
---
---
5
20
RS232_TX
---
---
3
21
C O N F 1
