NMC-DC
INSTALLATION MANUAL
Page: of 109 pagesRevision: 01 IDoc. Name: NMC-DC I Installation Manual
Crop Management Technologies
1.4 Power Supply Fuse Protection
Location Designation Type Style Rating Reaction Time Dimensions
NM-DC Power Supply, Solar Battery F1 Tubular Glass M205 5.0 Amp Slow Blow (T) 20mm x 5mm
NM-DC Power Supply, Main Battery F2 Tubular Glass M205 2.0 Amp Slow Blow (T) 20mm x 5mm
102
