NMC-DC
INSTALLATION MANUAL
Page: of 109 pagesRevision: 01 IDoc. Name: NMC-DC I Installation Manual
Crop Management Technologies
Sensor typeDip Switch position
Temperature sensor (30kΩ)Temp
Humidity0-5V
EC, pH, CO2…4-20mA
Outside Temp – IN 3 :
Outside Hum– IN 4 :
Sensor Wires
Temp&Hum sensor: Black - COM
Temp sensor: Red - Input
Hum sensor: Red - +12VDC
Hum sensor: White - Input
Cable type
4x0.5mm
2
(20AWG)
Sensor Installation and Definition
1. Outside Temp/Hum Sensor Connection
88
To Next Page
