SCREENGUARD
™
INSTALLATION AND USER MANUAL
11
DESCRIPTION
Wiring
Main parts
Battery compartment
PD sensor (underneath the
battery compartment)
PD sensor
control tube nuts
Cable gland
Manual flushing button
Battery compartment
or external
power supply (5v DC)
Manual flushing button
Aquative operator (solenoid)
PD sensor
Option: Filtron 1-10 flush controller
Optionally, SG filters can be supplied equipped with the Filtron 1-10 flush controller for additional control
features.
For operation of the Filtron 1-10 flush controller see its User Manual enclosed with it.
