SCREENGUARD
™
INSTALLATION AND USER MANUAL
43
REPLACEMENT PARTS
Part Description Cat. No. Qty.
5.1.1 Aquative DC 35500-001900 1
5.1. 2 Plug in Metal Connector 8mm X 1/8" 2
5.1. 3 Plug in Metal Connector 90 deg 8mm X 1/8" 1
Aquative DC Assembly
The Aquative DC Assembly consists of the following parts
Part Description Cat. No. Qty.
5.1 Aquative DC Assembly 71965-000261 1 set
Part Description Cat. No. Qty.
6.1 Three Way Valve 3 x 1/8" 1
6.2 Plug in Plastic Connector 90 deg 8mm X 1/8" 2
6.3 Plug in Plastic Connector 90 deg 6mm X 1/4" 1
6.4 Pressure Gauge 10Bar 1/4" BSP 77456-000153 1
6.5 Brass Connector Adaptor 1/4" X 1/8" M-M 1
6.6 Brass Connector Cross 1/4" 1
6.7 Brass Connector 1/4" X 1/4" M-M 1
6.8 Brass Connector 1/4" X 1/4" F-F 1
6.9 Plug in Plastic Double Connector 8 mm X 1/4" 1
Pressure Gauge Assembly
The Pressure Gauge Assembly consists of the following parts
Hydraulic Relay Assembly
Part Description Cat. No. Qty.
5.4.1 SG Hydraulic Relay 71680-000800 1
5.4.2 Brass Connector Adaptor 3/8" X 1/4" D-E 1
5.4.3 Brass Connector 1/4" X 1/4" F-F 1
5.4.4 Plug in Plastic Connector 8mm X 1/4" 1
5.4.5 Plug in Plastic Connector 90 deg 8mm X 3/8" 2
5.4.6 Plug in Plastic Connector 90 deg 6mm X 3/8" 1
The Hydraulic Relay Assembly consists of the following parts
Part Description
Cat. No.
Qty.SGV 2" SGV 3" SGV 3"S SGV 4" SGV 4"S SGV 6"
5.4 Hydraulic Relay Assembly 71965-000530 71965-000414 1
Part Description
Cat. No.
Qty.SGV 2" SGV 3" SGV 3"S SGV 4" SGV 4"S SGV 6"
6 Pressure Gauge Assembly 71965-000531 71965-000405 1
To Next Page
