Replacing a fan module in a DS460C disk shelf
Each DS460C drive shelf includes two fan modules. If a fan module fails, you must replace it as soon
as possible to ensure that the shelf has adequate cooling. When you remove the failed fan module,
you do not have to turn off power to your disk shelf.
About this task
You must ensure that you remove and replace the fan module within 30 minutes to prevent the system
from overheating.
Steps
1.
Put on antistatic protection.
2.
Unpack the new fan module, and place it on a level surface near the shelf.
Save all packing material for use when returning the failed fan.
3.
From the back of the disk shelf, look at the Attention LEDs to locate the fan module you need to
remove.
You must replace the fan module that has its Attention LED on.
Item
LED name State Description
Attention Solid
amber
The fan has a fault.
17
