NetComm NP508 User Manual

6
NP508 – 500Mbps Powerline Adapters User Guide
www.netcommwireless.com
LABEL
STATUS
DESCRIPTION/FUNCTION
A
WPS Button / Wireless LED
Off
No power
On

Press for 2 seconds to trigger the WPS function.

Press for more than 5 seconds to reset the device.

When the wireless LED is steady it means that the Wireless Function is enabled.
B
Power LED
Off
No power
On

When Simple Connect is pressed for more than 10 seconds, this LED turns OFF and turns
ON to confirm the Private Network Password reset.

After Simple Connect is pressed for 2 seconds, this LED blinks to confirm the button press.
C
Powerline Activity
Off
An Ethernet device is not connected.
On

When Simple Connect is pressed for more than 10 seconds and PLC is enabled, this LED
turns OFF to confirm the Private Network Password reset. If PLC is disabled, this LED
remains off.

This LED is steady in colour when the device is part of a network.

The LED colours represent the connection rate within the network whether it is good (red),
better (amber), or best (green).
D
Ethernet Activity
Off
An Ethernet device is not connected.
On

This LED is steady when an Ethernet device is connected.

The LED flashes to indicate Ethernet activity.
E
Ethernet Port
Accepts either cross or straight Ethernet cable.
F
Simple Connect Button
Press to create or join a network.
When Simple Connect is pressed for more than 10 seconds, the Private Network Password is
randomized.
Then Press for 2 seconds to pair the device.
G
Dual Band Switch (2.4GHz/5GHz)
This allows you to manually switch to either 2.4 Ghz or 5 Ghz frequency band.

NetComm NP508 Specifications

General

Brand	NetComm
Model	NP508
Category	Adapter
Language	English
