NP508 – 500Mbps Powerline Adapters User Guide
7
AC Passthrough Adapter
LABEL
STATUS
DESCRIPTION/FUNCTION
Power
Off
No power
On

Powerline adapter is in Power Saving Status when LED is blinking slowly.

When Simple Connect is pressed for 5-8 seconds, this LED will turn OFF and turn ON once
to confirm the Private Network Password reset.

After Simple Connect is pressed for 2-4 seconds, this LED will blink to confirm the button
press.
Powerline Activity
Off
Device is not connected to a Powerline adapter network.
On

When Simple Connect is pressed for 5-8 seconds, this LED will turn OFF to confirm the
Private Network Password reset.

This LED is steady in color when the device is part of a Powerline adapter network.

The LED colors represents the connection rate within the Powerline adapter network
whether it is good (red), better (amber), or best (green).
Ethernet Activity
Off
An Ethernet device is not connected.
On

When Simple Connect is pressed for 5-8 seconds, this LED will turn OFF to confirm the
Private Network Password reset.

This LED is steady in colour when the device is part of a Powerline adapter network.

The LED colours represent the connection rate within the Powerline adapter network
whether it is good (red), better (amber), or best (green).
Ethernet Port
Accepts either crossover or straight-through Ethernet cable.
Simple Connect Button
/ Reset Button

Press to create or join a Powerline adapter network. It can also be used to reset the Private
Network Password to a random key.

When Simple Connect is pressed for 5-8 seconds, it will randomize the Private Network
Password.

Press for 10-13 seconds to reset to the factory default settings. When you reset to the
factory default, all your configuration changes are removed.
