WDS AP configuration
Navigate to Networking -> Wireless settings -> AP basic.
Ensure that the AP radio toggle key is set to the ON position.
In the Frequency (channel) drop down list, select a channel. WDS cannot operate when the access point is set to AUTO,
so you must select a specific channel.
In the SSID field, enter a network name for the WDS network.
Select the WDS (AP mode) enable toggle key so that it is in the ON position.
Set the other wireless settings as you require. Refer to the AP basic section for further detail.
Figure 45 - WDS AP example configuration
Click the Save button. A warning is displayed.
Click the OK button. Your settings are saved.
