Hardware Overview
18
AC1900, N900, and N450 WiFi Cable Data Gateways
Power Solid green. The cable data gateway is receiving power.
Blinking green. The
cable data gateway is powering on.
Blinking red.
The cable data gateway is performing a self-test or the thermal
cutoff circuit was triggered.
Off.
The cable data gateway is not receiving power.
Note: If the Power LED lights red or blinks red at any other time than while booting,
see Troubleshoot with the LEDs on page 155.
Downstream
Solid blue. More than one downstream channel is locked.
Solid green. One downstream channel is locked (channel bonding does not
occur).
Blinking green.
The cable data gateway is scanning for a downstream
channel.
Off. No downstream channel is locked.
Upstream
Solid blue. More than one upstream channel is locked.
Solid green. One upstream channel is locked (channel bonding does not
occur).
Blinking green.
The cable data gateway is scanning for an upstream channel.
Off. No upstream channel is locked.
Internet
Solid green. The cable data gateway is connected to the Internet.
Slow blinking green.
The cable data gateway is receiving DHCP information
from the cable provider’s cable modem termination system (CMTS).
Fast blinking green. The
cable data gateway is downloading a configuration
file from the cable provider’s CMTS.
Off.
The cable data gateway is not connected to the Internet.
LAN
The type of Ethernet connection determines the LED color:
A green LED indicates a 1,000 Mbps connection.
An amber LED indicates a 100/10 Mbps connection.
The LED functions are as follows:
Solid green or amber. The
Ethernet port is connected to a powered-on device.
Blinking green or amber. Data is being transmitted or received on the Ethernet
port.
Off.
The Ethernet port does not detect a powered-on device.
Table 3. LEDs and front panel buttons of the N450 (continued)
LED Icon Description
