NETGEAR DOCSIS C6230 User Manual

Table 4. Factory default settings (Continued)
Default behaviorFeature
EnabledWiFi communicationWiFi
See the cable modem labelSSID name
WPA2-PSK (AES)Security
EnabledBroadcast SSID
United StatesCountry/region
Auto
1
RF channel (2.4 GHz)
CH 157 (or manually select Band 1 and 4
Channels)
RF channel (5 GHz)
Up to 300 Mbps at 2.4 GHz
Up to 900 at 5 GHz
Operating mode
1
Maximum WiFi signal rate derived from IEEE Standard 802.11 specifications. Actual throughput can vary. Network
conditions and environmental factors, including volume of network traffic, building materials and construction, and
network overhead, lower actual data throughput rate.
Technical Specifications
Table 5. Modem router specifications
DescriptionFeature
TCP/IP, DHCP, Dynamic DNS, UPnP, and SMBData and routing protocols
120V, 60 Hz, input
12V/2.5 A DC output
Power adapter (North America)
8.14 x 4.88 x 2.91 in (207 x 124 x 74 mm)Dimensions
0.79 lbs (360 g)Weight
32º to 104º F (0° to 40° C)Operating temperature
90% maximum relative humidity, noncondensingOperating humidity
FCC Part 15 Class BElectromagnetic emissions
10BASE-T or 100BASE-TX or 1000BASE-T, RJ-45LAN
16 x 4 DOCSIS 3.0 WAN InterfaceWAN
User Manual106Supplemental Information
C6230 WiFi Cable Modem Router

NETGEAR DOCSIS C6230 Specifications

General

DOCSIS Version	3.0
Channel Bonding	16x4
Downstream Channels	16
Upstream Channels	4
WiFi Standard	802.11ac
Ethernet Ports	2
WiFi Technology	Dual Band
Compatibility	Xfinity, Spectrum, Cox
USB Ports	1
