NETGEAR EAX12 User Manual

Note: Since your router and extender networks share the same WiFi network name,
only one WiFi network name is broadcast.
Connect with the NETGEAR installation assistant
You can use the NETGEAR installation assistant to connect your extender to your existing
WiFi router network. To use the NETGEAR installation assistant, you must launch a web
browser on your computer or mobile device.
To use the NETGEAR installation assistant to connect the extender to your WiFi
router:
1. On your WiFi-enabled computer or mobile device, open the WiFi connection
manager and locate and connect to the extender network called NETGEAR_EXT.
2. Launch web browser.
3.
Enter http://www.mywifiext.net/.
The NETGEAR installation assistant displays.
4. Follow the prompts to connect your extender to your existing router WiFi network.
5. Unplug your extender and move it to a new location.
We recommend that the new location be about halfway between your router and
the area with a poor WiFi signal.
6. Power on your extender.
7. Use the Router Link LED to help you choose a spot where the extender-to-router
connection is optimal.
8.
If the Router Link LED doesn’t light green, plug the extender into an outlet closer to
the router and try again.
Keep moving the extender to outlets closer to the router until the Router Link LED
lights green.
9. Reconnect your computer or mobile device to the new extended WiFi network.
User Manual17Get started
AX1600 4-Stream WiFi 6 Mesh Extender

NETGEAR EAX12 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Security algorithms	128-bit AES, WPA3-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power over Ethernet (PoE)	No
Placement	Wall
Product color	White
Housing material	Plastic
Antenna type	Internal
Antennas quantity	2
Number of products included	1 pc(s)
Package type	Box
Processor frequency	880 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	52.3 mm
Width	68.4 mm
Height	149 mm
Weight	490 g
