4. Enter the saved answers to your security questions.
5. Click the NEXT button.
Your admin user name address and password are displayed.
6. Click the BACK button.
A login page displays.
7. Log in to the extender.
Automatically adjust for daylight saving time
To set up the extender to automatically adjust for daylight saving time:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 65.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
5. Select Do More > Access Schedule.
The Access Schedule page displays.
6.
Select the Automatically adjust for daylight savings time check box.
7. Click the SAVE button.
Your settings are saved.
User Manual51Maintain and monitor the
extender
AX1600 4-Stream WiFi 6 Mesh Extender

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR EAX12 and is the answer not in the manual?

NETGEAR EAX12 Specifications

General IconGeneral
2.4 GHzYes
Frequency band2.4 - 5 GHz
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1200 Mbit/s
Maximum data transfer rate (2.4 GHz)400 Mbit/s
Security algorithms128-bit AES, WPA3-PSK
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports1
Power over Ethernet (PoE)No
PlacementWall
Product colorWhite
Housing materialPlastic
Antenna typeInternal
Antennas quantity2
Number of products included1 pc(s)
Package typeBox
Processor frequency880 MHz
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth52.3 mm
Width68.4 mm
Height149 mm
Weight490 g
