By default, the Dynamically get IP Address from Router radio button is selected.
7. Select the Use Static IP Address radio button.
8.
Complete the fields to specify the IP network IP addresses.
9. Click the SAVE button.
Your settings are saved.
Adjust the WiFi coverage
You can adjust the extender output power percentage and range of your extended WiFi
network. If you select a low output power percentage, the extender's WiFi range will
be shorter, and the extender uses less power. If you select a high output power
percentage, the extender's WiFi range will be longer, and the extender uses more
power.
For a smaller coverage area, choose a lower output power percentage. For a larger
coverage area, select a higher output power percentage.
To adjust the WiFi coverage:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
•
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
•
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 65.
A login page displays.
3. Enter your admin user name and password and click the LOG IN button.
The Status page displays.
4.
If your browser displays the Menu icon , click it.
The extender menu displays.
User Manual43Extender Network Settings
AX1600 4-Stream WiFi 6 Mesh Extender
