Page #50 background imageLoading...
Page #50 background image
6.
Select the Password On or Password Off radio button:
Password On: Select this option is you want to turn on password protection for
your extender web interface. If you select this option, you are required to enter
a password when you log in to the extender.
Password Off: Select this option is you want to turn off password protection for
your extender web interface. If you select this option, you are not required to
enter a password when you log in to the extender.
7. Click the SAVE button.
Your settings are saved.
Recover a forgotten user name or password
If you changed the password that you use to access the extender and you set up
password recovery, you can recover your password if you lose it.
To recover your password that you use to access the extender:
1.
Launch a web browser from a computer or mobile device that is connected to your
extender network.
2. Log in to your extender:
If you did not enable the One WiFi Name feature, enter
http://www.mywifiext.net/ in the address field of the browser.
If you enabled the One WiFi Name feature, enter one of the following URLs:
-
Windows-based computers. http://mywifiext/ or http://mywifiext.local/
-
Mac computers, iOS devices, and Linux devices. http://mywifiext.local/
-
Android devices. http://<extender’s IP address>/ (for example,
http://192.168.1.3/)
For more information about how to find your extender’s IP address, see Find
the Extender’s IP address on page 65.
A login page displays.
3. Click the Username & Password Help link.
A page displays requesting the answers to your security questions.
If you forgot the answers to your security questions, restore the extender’s factory
settings and set up your login credentials again. See Return the extender to its factory
default settings on page 56.
User Manual50Maintain and monitor the
extender
AX1600 4-Stream WiFi 6 Mesh Extender

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the NETGEAR EAX12 and is the answer not in the manual?

NETGEAR EAX12 Specifications

General IconGeneral
2.4 GHzYes
Frequency band2.4 - 5 GHz
Cabling technology10/100/1000Base-T(X)
Networking standardsIEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates10, 100, 1000 Mbit/s
Maximum data transfer rate1200 Mbit/s
Maximum data transfer rate (2.4 GHz)400 Mbit/s
Security algorithms128-bit AES, WPA3-PSK
USB 2.0 ports quantity0
Ethernet LAN (RJ-45) ports1
Power over Ethernet (PoE)No
PlacementWall
Product colorWhite
Housing materialPlastic
Antenna typeInternal
Antennas quantity2
Number of products included1 pc(s)
Package typeBox
Processor frequency880 MHz
Harmonized System (HS) code85176990
Weight and Dimensions IconWeight and Dimensions
Depth52.3 mm
Width68.4 mm
Height149 mm
Weight490 g
