NETGEAR EAX12 User Manual

Factory Default Settings
To reset the extender to factory default settings, you can use the Reset button on the
side panel or you can log in and click the onscreen RESET button. For more information,
see Return the extender to its factory default settings on page 56.
The following table shows the factory default settings.
Table 10. Factory default settings
Default SettingsFeature
EnabledSmart Setup
EnabledWiFi communication
NETGEAR_EXTWiFi network name (SSID)
DisabledSecurity
Auto
1
Transmission speed
Varies by regionCountry/region
802.11a/b/g/n/ac/axOperating mode
Max 400 MbpsData rate in the 2.4 GHz band
Disabled by default
(When enabled the max data rate is 1200 Mbps)
Data rate in the 5 GHz band
Server and client are enabledDHCP
1
Maximum WiFi signal rate (IEEE Standard 802.11). Actual throughput can vary. Network conditions and environmental
factors, including volume of network traffic, building materials and construction, and network overhead lower actual
data throughput rate.
User Manual70Supplemental Information
AX1600 4-Stream WiFi 6 Mesh Extender

NETGEAR EAX12 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Security algorithms	128-bit AES, WPA3-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power over Ethernet (PoE)	No
Placement	Wall
Product color	White
Housing material	Plastic
Antenna type	Internal
Antennas quantity	2
Number of products included	1 pc(s)
Package type	Box
Processor frequency	880 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	52.3 mm
Width	68.4 mm
Height	149 mm
Weight	490 g
