NETGEAR EAX12 User Manual

Table 1. LED descriptions
DescriptionLED
•
Solid amber. The extender is booting.
•
Solid green. The extender is powered on.
•
Off. The extender is powered off.
Power LED
This LED indicates the WiFi connection between the extender and the router.
•
Solid green. Best connection.
•
Solid amber. Good connection.
•
Solid red. Poor connection.
•
Off. No connection.
Router Link LED
This LED indicates the a connection between the extender and a WiFi-enabled
computer or mobile device.
•
Solid green. Best connection.
•
Solid amber. Good connection.
•
Solid red. Poor connection.
•
Off. No connection.
Client Link LED
•
Blinking green. A WPS connection is being established.
•
Solid green. The extender is connected to the router WiFi network, and the
extender network is set up with WiFi security (either WPA, WPA2, or WPA3
WiFi security).
•
Off. The extender network is set up without WiFi security.
WPS LED
User Manual8Overview
AX1600 4-Stream WiFi 6 Mesh Extender

NETGEAR EAX12 Specifications

General

2.4 GHz	Yes
Frequency band	2.4 - 5 GHz
Cabling technology	10/100/1000Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Ethernet LAN data rates	10, 100, 1000 Mbit/s
Maximum data transfer rate	1200 Mbit/s
Maximum data transfer rate (2.4 GHz)	400 Mbit/s
Security algorithms	128-bit AES, WPA3-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Power over Ethernet (PoE)	No
Placement	Wall
Product color	White
Housing material	Plastic
Antenna type	Internal
Antennas quantity	2
Number of products included	1 pc(s)
Package type	Box
Processor frequency	880 MHz
Harmonized System (HS) code	85176990

Weight and Dimensions

Depth	52.3 mm
Width	68.4 mm
Height	149 mm
Weight	490 g
