NETGEAR GS105Ev2 User Manual

The default password is password. The password is case-sensitive.
The Switch Information page displays.
5.
Select VLAN.
The Basic Port-based VLAN Status page displays.
6.
If this is the first time that you are accessing this page or if you are changing the
VLAN assignment method, select the Enable radio button and continue with Step
7.
Otherwise, see Step 9.
A pop-up window opens, informing you that the current VLAN settings will be lost.
7.
Click the OK button.
The pop-up window closes.
8.
Click the Apply button.
Your settings are saved.
The Basic Port-based VLAN Group table displays.
The previous figure is an example. Your switch might provide more or fewer ports.
9.
Under each port to be added to a VLAN, enter the ID of the VLAN.
You can enter a VLAN ID from 1 to the maximum number of ports that your switch
supports. If all the VLANs share an uplink to the Internet or servers, enter all in the
VLAN ID field for the port that you want to use for the uplink.
Note: If ports are members of the same LAG, you must assign them to the same
VLAN.
10.
Click the Apply button.
Your settings are saved.
User Manual23Use VLANS for Traffic
Segmentation
Gigabit Ethernet Smart Managed Plus Switches

NETGEAR GS105Ev2 Specifications

General

Model	GS105Ev2
Category	Switch
Ports	5
Switching Capacity	10 Gbps
Forwarding Rate	7.4 Mpps
VLAN Support	Yes
Quality of Service (QoS)	Yes
Energy Efficient Ethernet (EEE)	Yes
Power Supply	External Power Adapter
Storage Temperature	-20° to 70° C (-4° to 158° F)
Operating Temperature	0°C to 40°C
Humidity	90% maximum relative humidity, noncondensing
Standards Compliance	IEEE 802.3, IEEE 802.3u, IEEE 802.3az
Dimensions	6.22 x 4.02 x 1.10 in (158 x 102 x 28 mm)
Weight	0.24 kg (0.53 lb)
Jumbo Frame Support	Yes
