NETGEAR GS716T Hardware Installation Guide

26
GS716T, GS724T and GS748T Gigabit Smart Switch
Troubleshooting Chart
The following table lists symptoms, causes, and solutions of possible problems.
Table 5. Troubleshooting Chart
Symptom Cause Solution
Power LED is off. No power is received. Check the power cord connections for the switch at
th
e switch and the connected device. Ensure all
cables used are correct and comply with Ethernet
specifications.
Link LED is off or
intermitt
ent.
Port connection is not
working.
Check the crimp on the connectors and make sure
that the plug is properly inserted and locked into the
port at both the switch and the connecting device.
Ensure all cables used are correct and comply with
Ethernet specifications. Check for a defective
adapter card, cable, or port by testing them in an
alternate environment where all products are
functioning.
File transfer is slow or
performance d
egradation
is a problem.
Half-duplex or full-duplex
setting on the switch and
the connected device are
not the same.
Make sure the attached device is set to
auto-negotiate.
A segment or device is
not
recognized as part of
the network.
One or more devices are
not properly connected,
or cabling does not meet
Ethernet guidelines.
Verify that the cabling is correct. Ensure all
connectors are securely positioned in the required
ports. Equipment may have been accidentally
disconnected.
ACT LED is flashing
co
ntinuously on all
connected ports and the
network is disabled.
A network loop
(redundant path) has
been created.
Break the loop by ensuring that there is only one
path from any networked device to any other
networked device.

NETGEAR GS716T Specifications

General

Switch type	Managed
Switch layer	L3
Quality of Service (QoS) support	Yes
Stackable	-
Certification	CE, FCC, VCCI, EN, C-Tick, CCC, CSA, UL/cUL, IEC
Product color	Blue
LED indicators	Activity, Link, Power
SFP module slots quantity	2
Basic switching RJ-45 Ethernet ports type	Gigabit Ethernet (10/100/1000)
Basic switching RJ-45 Ethernet ports quantity	16
Number of VLANs	256
Networking standards	IEEE 802.1D, IEEE 802.1as, IEEE 802.1s, IEEE 802.1v, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3i, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z
Copper ethernet cabling technology	10BASE-T, 100BASE-TX, 100BASE-T, 1000BASE-T
Noise level	0 dB
Mean time between failures (MTBF)	567680 h
DHCP features	DHCP client
Security algorithms	802.1x RADIUS, HTTPS, SSL/TLS
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (typical)	14.4 W
MAC address table	16000 entries
Number of static routes	32
Operating altitude	0 - 3000 m
Storage temperature (T-T)	-20 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Storage relative humidity (H-H)	0 - 95 %
Operating relative humidity (H-H)	0 - 90 %
Cables included	AC
Supported network protocols	IP

Weight and Dimensions

Depth	204 mm
Width	440 mm
Height	43 mm
Weight	2570 g
