Table 1. Front panel LED descriptions
LED Description
Power
• Solid green. The power is on, and the router is ready.
• Blinking green. A
firmware update is in progress.
• Off. Power is not supplied to the router.
Internet
• Solid green. An IP address was received; the router is ready to transmit data.
• Off. No Ethernet cable is connected between the router and the modem.
WiFi
• Solid green. The wireless radio is operating.
• Off. The
wireless radio is off.
Ethernet
ports 1–4
• Solid green. The Ethernet port has detected a 100 Mbps link with an attached device.
• Off.
The Ethernet port has not detected a link with an attached device.
Hardware Setup
9
JWNR2010v5 N300 Wireless Router
