5. Select the Enable VLAN/Bridge Group check box.
6. Select the By VLAN tag group radio button.
7. Specify the settings as described in the following table.
DescriptionField
Enter a name for the VLAN tag group.
The name can be up to 10 characters.
Name
Enter a value from 1 to 4094.VLAN ID
Enter a value from 0 to 7.Priority
Select the check box for a wired LAN port or WiFi port.
If your device is connected to an Ethernet port on the router, select the LAN port check box that corresponds to the Ethernet
port on the router to which the device is connected. If your device is connected to your router’s WiFi network, select the
WiFi check box that corresponds to the router’s WiFi network to which the device is connected.
You must select at least one LAN port or WiFi port.You can select more than one port.
8. Click the Add button.
The VLAN tag group is added.
9. Click the Apply button.
Network Settings
79
Nighthawk X8 AC5300 Tri-Band WiFi Router
