This IP address must be in the same subnet as the router. The default ending IP
address is 192.168.20.254.
7.
In the lease time hour(s) field, set the duration of the IP address lease in hours.
By default, the lease expires after one day (24 hours), after which the WiFi client must
renew the lease.
8. Click the Apply button.
Your settings are saved.
The router delivers the following parameters to any LAN device that requests DHCP:
•
An IP address from the range that you defined
•
Subnet mask
•
Gateway IP address (the router’s LAN IP address)
•
DNS server IP address (the router’s LAN IP address)
Set up a DHCP server for the IoT LAN 3
The DHCP IP addresses for the IoT LAN 3 must be part of the same IP address subnet
as the router’s default LAN IP address. Using the default addressing scheme, define a
range between 192.168.30.2 and 192.168.30.254, although you can save part of the
range for devices with fixed addresses.
To set up the DHCP server for the IoT LAN 3:
1.
Launch a web browser from a computer or mobile device that is connected to your
Orbi network.
2. Enter orbilogin.com.
A login window displays.
If your browser does not display a login window but displays a security warning and
does not let you proceed, see What to do if you get a browser security warning on
page 33.
3. Enter the admin user name and password.
The user name is admin. The password is the one that you set the first time that you
logged in. The user name and password are case-sensitive.
The BASIC Home page displays.
4. Select ADVANCED > Setup > LAN Setup > LAN 3.
The LAN Setup page displays.
User Manual122Manage the LANs
Orbi Pro WiFi 6 AX6000 Router Model SXR80 and Orbi Pro WiFi 6 AX6000 Satellite Model SXS80
