NETGEAR ProSAFE S3300 User Manual

Physical Description
12
S3300 Smart Switch
The front panel provides the following components:
• Forty eight RJ-45 connectors for 10/100/1000 Mbps autosensing Gigabit Ethernet
switching ports
• Two 100M/1G/10GBASE-T copper ports (49–50) that you can also use for stacking
• Two 10G/1G SFP+ fiber ports (51–52) that you can also use for stacking
• One USB 2.0 port that supports FA
T32 and VF
AT file systems
• Reset button to restart the device
• Recessed Factory Defaults button to restore the device back to the factory defaults
• Link, Speed, and
Activity LEDs for each port and for the PoE model, PoE LEDs for
ports 1–48
• Power, Fan, and Stack ID LEDs; for model S3300-52X-PoE+ only, PoE Max LED
The following figures illustrate the back panel of models S3300-52X and S3300-52X-PoE+:
Console port
Kensington lock
AC input connector
Figure 4. Back panel model S3300-52X
Console port
Kensington lock
AC input connector
RPS slot
Figure 5. Back panel model S3300-52X-PoE+
From left to right, the back panel provides the following components:
• Serial console port that is configured for 115200, N, 8, 1. The serial port is for debugging
purposes by NETGEAR support. (The port requires a special adapter
.)
• Slot for an optional redundant power supply (RPS, model S3300-52X-PoE+ only).
• Kensington lock.
• AC power input connector
.

NETGEAR ProSAFE S3300 Specifications

General

Uplink Ports	4 x 10G SFP+
Power Supply	Internal power supply
Switching Capacity	176 Gbps (52-port)
Management	Web-based, SNMP
Dimensions	17.3 x 1.7 in
Forwarding Rate	131 Mpps (52-port models)
VLAN Support	Yes
Jumbo Frame Support	Yes
Operating Temperature	32°F to 122°F (0°C to 50°C)
Storage Temperature	-20° to 70° C (-4° to 158° F)
Humidity	90% maximum relative humidity, noncondensing
