NETGEAR R6900v2 User Manual

The user name is admin.The default password is password.The user name and password are
case-sensitive.
The BASIC Home page displays.
4. Select Attached Devices.
Wired devices are connected to the router with Ethernet cables.WiFi devices are connected to the
router through the WiFi network, in either the 2.4 GHz band or one of the 5 GHz bands.
The following table describes the fields that can be displayed.
DescriptionField
The status of the device in the network (Allowed or Blocked).Status
The name of the WiFi network to which the device is connected.SSID
The IP address that the router assigned to the device when it joined the network. This
address can change when a device is disconnected and rejoins the network.
IP Address
The unique MAC address.The MAC address does not change and is usually shown on the
product label.
MAC Address
The device name, if detected.Device Name
The type of connection for the device.Connection
Type
5. To refresh the information onscreen, click the Refresh button.
The information onscreen is updated.
Manage the Router and Monitor the Traffic
169
Nighthawk AC1900 Smart WiFi Router Model R6900v2

NETGEAR R6900v2 Specifications

General

WiFi Technology	802.11ac
WiFi Performance	AC1900 (600 + 1300 Mbps)
USB Ports	1 USB 3.0 port
Antenna	3 external antennas
Processor	Dual Core 1GHz
Frequency Band	Dual Band 2.4 GHz / 5 GHz
Memory	128MB Flash, 256MB RAM
Security	Guest Network Access
Dimensions	11.22 x 7.26 x 1.97 inches
Number of Ethernet Ports	5 x 10/100/1000 Mbps Gigabit Ethernet ports (1 WAN & 4 LAN)
