NETGEAR RangeMax WNDA3100 User Manual

NETGEAR RangeMax Dual Band Wireless-N USB Adapter WNDA3100 User Manual
2-8
v1.0, December 2007
2. Enter the network settings.
a. Select Computer-to-Computer (Ad Hoc) for the network type.
b. Select or enter the network name (SSID) for the Ad Hoc network.
c. In the Profile field, type the name of the profile.
d. Click Apply.
3. Save your settings in a profile.
a. Click Save Profile, and all the configuration settings are saved in this profile.
b. Click Apply, then click Close to exit the Smart Wizard, or click Cancel to return to the
previous settings.
4. Configure the computer network settings.
a. Configure each computer with either a static IP address or with the IPX protocol.
b. Restart the computers.
5. Verify wireless connectivity between your peer devices with the ping program:
a. On the Windows taskbar, select Start > Run.
b. Assuming the target PC is configured with 192.168.0.1 as its IP address, type:
ping -t 192.168.0.1
and then click OK.
Figure 2-6

NETGEAR RangeMax WNDA3100 Specifications

General

Category	Wireless Adapter
Interface	USB 2.0
Wireless Standards	IEEE 802.11a/b/g/n
Frequency Band	2.4 GHz / 5 GHz
Wireless Data Rates	Up to 300 Mbps
Security	WEP, WPA-PSK, WPA2-PSK
Operating Systems Supported	Windows XP, Windows Vista
