Orbi Wall Plug Satellite Model RBW30 Hardware Overview
Figure 7. Orbi wall plug satellite model RBW30, front and back views
1. Ring LED (not shown in image)
2. Sync button (also used for WPS connection)
3. Reset button
LED Behavior
When you sync a satellite to the router, the LED behavior for a satellite that comes in a
WiFi system is different from the LED behavior for add-on satellites.
Orbi WiFi System LEDs
The following table describes the LED behavior for an Orbi router and Orbi satellites
that are purchased together and come in the same package.
User Manual15Overview
Orbi WiFi System
