NETGEAR ReadyNAS 2120

6. System reset switch
7. USB port
Rear Panel
The following figure shows the rear panel of the ReadyNAS 4360 storage system.
4
1 5 2
3
6
7
8
Figure 29. Rear panel
1. 1 Gbps LAN ports
2. USB 3.0 ports
3. 10 Gbps LAN ports (RR4360S: optical SFP+; RR4360X: copper 10GBASE-10)
4. Power supply bay
5. Power supply including fans
6. Power supply including fans
7. Power supply bay
8. Three mini SAS ports
The RR4360 chassis supports up to four power supplies.Two are required. As long as two remain operating,
the supplies are hot swappable.
ReadyNAS 4360
66
ReadyNAS OS 6
