Replace the On-Board Battery on a ReadyNAS 3220, 3312, 4220,
4312, or 4360
To replace the battery of a ReadyNAS 3220, 3312, 4220, 4312, or 4360 storage system:
1. Open the system and locate the battery holder.
The following figure shows the location of the battery holder for the ReadyNAS 3302 and 4220 systems.
The battery holder in the ReadyNAS 3312, 4312, and 4360 systems is located toward the front left
corner of the enclosure.
2. Remove the old battery.
3. Install the new battery.
Take care to install the new battery with the correct side up.
Maintenance
99
ReadyNAS OS 6
